Arabirim Gigabit Ethernet (RJ-45) Port×1 (Support IEEE802.3af PoE and Passive PoE) Fiziksel Güvenlik Kilidi Yes Buton Reset Güç Kaynağı • 802.3af/at PoE • 24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included) Güç Tüketimi • EU: 10.5 W • US: 12.6 W Boyutlar ( W X D X H ) 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm) Anten Tipi 3 Internal Omni • 2.4 GHz: 4 dBi • 5 GHz: 5 dBi Montaj Ceiling /Wall Mounting (Kits included) KABLOSUZ ÖZELLİKLERİ Kablosuz Standartlar IEEE 802.11ac/n/g/b/a Frekans 2.4 GHz and 5 GHz Bağlantı Hızı • 5 GHz:Up to 867 Mbps • 2.4 GHz:Up to 450 Mbps Kablosuz Fonksiyonlar • Multiple SSIDs (Up to 16 SSIDs, 8 for each band) • Enable/Disable Wireless Radio • Automatic Channel Assignment • Transmit Power Control (Adjust Transmit Power on dBm) • QoS(WMM) • Seamless Roaming* • Omada Mesh* • Band Steering • Load Balance • MU-MIMO • Airtime Fairness • Beamforming • Rate Limit • Reboot Schedule • Wireless Schedule • Wireless Statistics based on SSID/AP/Client Kablosuz Güvenlik • Captive Portal Authentication* • Access Control • Wireless Mac Address Filtering • Wireless Isolation Between Clients • SSID to VLAN Mapping • Rogue AP Detection • 802.1X Support İletim Gücü • CE: ≤20 dBm(2.4 GHz, EIRP) ≤23 dBm(5 GHz, EIRP) • FCC: ≤24 dBm(2.4 GHz) ≤22 dBm(5 GHz) YÖNETİM Omada App Yes Centralized Management • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller Cloud Access Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller) Eposta Uyarı Yes LED Açık/Kapalı Kontrolü Yes MAC Erişim Kontrolü Yönetimi Yes SNMP v1,v2c Yerel/Uzak Sistem Günlüğü Kaydı Local/Remote Syslog SSH Yes Web-tabanlı Yönetim HTTP/HTTPS L3 Yönetim Yes Multi-site Yönetim Yes Management VLAN Yes DİĞERLERİ Sertifika CE, FCC, RoHS Paket İçeriği • AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225 • Passive PoE Adapter • Power Cord • Mounting Kits • Installation Guide Sistem Gereksinimleri Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux Ortam • Operating Temperature: 0–40 ℃ (32–104 ℉) • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
